金属泰勒花环填料

金属泰勒花环是在塑料泰勒环基础上发展而来的一种高效塔填料，它继承了泰勒环的基本结构优势，同时凭借金属材质的特性，在更严苛的工业环境中展现出优异的性能。其结构同样由 12 个小圆环按径向排列组成大扁球体，类似螺旋形弹簧首尾相接绕成的圆球，这种设计让它在气液传质过程中表现出色。...

产品询盘

金属泰勒花环是在塑料泰勒环基础上发展而来的一种高效塔填料，它继承了泰勒环的基本结构优势，同时凭借金属材质的特性，在更严苛的工业环境中展现出优异的性能。其结构同样由 12 个小圆环按径向排列组成大扁球体，类似螺旋形弹簧首尾相接绕成的圆球，这种设计让它在气液传质过程中表现出色。

产品特点

高强度与耐高温性：金属材质赋予泰勒环极高的机械强度，能承受较大的压力和温度变化，可适应高温、高压等恶劣工况，适用于化工、石油、冶金等行业的严苛生产环境。

优良的导热性：相比塑料材质，金属泰勒环具有更好的导热性能，在涉及热量传递的工艺中，能促进热量的快速传递与均匀分布，提升过程效率。

高传质效率与稳定性：延续了泰勒环结构的优势，金属环空隙率合理，气液接触充分，液体停留时间长，传质效率高且稳定。同时，金属表面的特性有助于减少液膜阻力，进一步优化传质效果。

耐腐蚀性可选：可根据介质特性选择不同的金属材质，如不锈钢（304、316 等）具有良好的耐腐蚀性，能应对酸碱等腐蚀性介质；碳钢材质则适用于无腐蚀或低腐蚀环境，兼顾经济性与实用性。

应用领域

高温高压反应塔：在高温高压的反应塔中，金属泰勒环能稳定发挥作用，适用于合成氨、甲醇合成等化工反应过程，保障反应的高效进行。

油气分离与精制：在石油炼制、油气分离等工艺中，可用于精馏塔、吸收塔等设备，实现油气组分的精确分离与精制，提高产品纯度。

环保脱硫脱硝：在工业废气脱硫、脱硝处理中，金属泰勒环凭借其耐温、耐腐特性，能有效促进气液反应，提升脱硫脱硝效率，助力环保达标。

冶金与焦化行业：在冶金行业的气体净化、焦化行业的煤气处理等过程中，可用于脱除杂质气体，净化工艺介质，保障后续生产的顺利进行。

产品参数表

规格（D×H×δmm）
堆积个数（n/m³）
比表面积（αm²/m³）
空隙率（ε%）
堆积重量（kg/m³）
常用材质
25×9×0.8
180000
200
85
280
304 不锈钢、316 不锈钢、碳钢
40×15×1.0
50000
190
88
320

50×18×1.2
28000
185
90
300

76×25×1.5
9500
130
92
260

100×30×1.8
4200
105
93
240

150×45×2.0
1200
75
95
210

产品询盘
